XONE:02 Service Manual 15
ORDERING A XONE:02 SPARES KIT
It is recommended that the spares kit order code 002-766 is held and maintained by the service agent
to enable in-field service repairs to the XONE:02 independent of the ALLEN & HEATH factory.
Commonly available items such as resistors, capacitors, tools and soldering equipment are not
included. The contents of the kit are listed below and are supplied in a cabinet of drawers. Individual
spare parts may be ordered. Please quote the description and order code for the part required.
Fixings:
DESCRIPTION ORDER CODE QTY
SCREW 4ABX5/16 CSK TORX BK AB0059 10
SCREW M3X6MM PAN TORX BK AB0072 15
SCREW M3X10 PAN TORX BK AB0076 3
NUT M3 NYLOCK AB0102 5
SCREW M3X6 CSK TORX BK AB0215 10
SCREW 4ABX1/4 PAN TORX PLTD AB0252 4
JOINT BLOCK 30% GLASS FILLED AB0253 5
WASHER M5 SHAKEPROOF AB0304 5
SCREW 4X5/16 PAN POLY TORX BK AB2810 20
SCREW M3X4 CSK TORX BK AB2811 10
SCREW M2.5X6 CSK POZI S/S AB4502 10
SCREW M2.5X4 CSK POZI BK AB4692 10
SCREW M2X3 CSK POZI S/S AB4704 20
NUT POT 9MM BLACK AB8172 30
FEET FAST 20DIA P4X5 AK0102 4
Knobs and caps:
DESCRIPTION ORDER CODE QTY
PUSH BTN BLACK ROUND AJ2887 3
KNOB CAP SOFT SIL-BL LINE P300 AJ4245 10
FADER KNOB BK-WH LINE AJ4247 10
PUSH BTN ROUND BLACK 8MM AJ4251 10
FADER KNOB BK-WH LINE REAN AJ4302 15
KNOB CAP SOFT SIL-WHI LINE P300 AJ4346 15
SWITCH CAP TALL AJ8071 3
Faders, Potentiometers, Switches and connectors:
DESCRIPTION ORDER CODE QTY
FLEX CABLE 39WAY 200MM 4 TAILS AH2900 2
POT ALPS 11MM 10K SPCL (103) AI3838 5
FADER ALPHA 30MM 10KBX2 AI4301 10
POT ALPS 11MM 20KK (203K) AI8003 3
POT ALPS 11MM 20KB C/D (203B) AI8004 3
