16 XONE:02 Service Manual
POT ALPS 14MM 20KKX2 ST (203K) AI8007 10
SWITCH 2PCO LATCH SINGLE AL0162 5
JACK SKT STEREO SW PCB CHROME AL0328 1
SWITCH 4PCO LATCH AL0333 3
SWITCH ALPS 6PCO LATCH AL0354 2
XLR FEM 3PIN VERT PCB AL2410 3
XLR MALE 3PIN VERT PCB AL2411 3
JACK SKT 1/4" ST V MET AL3410 5
PHONO DUAL VERT PCB 24MM GOLD AL3753 5
SWITCH LEVER DPCO AL4483 10
SWITCH ALPS 2PCO LATCH V AL8057 5
SPARE ASSY XONE02 LINE FADER 002-779 1
SPARE ASSY XONE02 X-FADE 002-780 2
LEDs and Semiconductors:
DESCRIPTION ORDER CODE QTY
ZENER DIODE BZX85 5V6 1.3W AE0012 5
TRANSISTOR BC549 NPN AE0020 2
IC TL072 OP-AMP AE0046 5
IC LM339N COMPARATOR AE0071 3
TRANSISTOR J111N FET T092B AE0083 5
LED T1 3MM YELLOW AE0084 3
LED T1 3MM GREEN AE0085 3
LED T1 3MM RED AE0086 3
IC NE5532N OP-AMP AE0221 3
ZENER DIODE BZX55C2V7 400MW AE0231 5
LED BAR MB 12/8G/3Y/1R AE2701 2
TRANSISTOR BC556B PNP AE3001 2
DIODE BYV27-400 2A 400V AE3469 5
DIODE BYV26E 1A 1000V AE3470 3
DIODE P6KE200A (TAPED) AE3471 3
TRANSISTOR MOSFET STP4NB80FP AE3472 3
IC SMPS UC3842AN AE3473 3
IC TL431 VOLTAGE REFERENCE AE3475 3
BRIDGE RECTIFIER 2KBP06M AE3477 3
IC SSM2164 VCA AE3688 2
IC LA6515 POWER OP-AMP AE3707 3
LED T1 3MM BLUE AE4041 3
IC THAT2155 VCA AE4279 1
IC THAT2181LC VCA AE5473 1
IC TLC072C OP-AMP CMOS AE4604 5
