XONE:02 Service Manual 5
Key Features
• Dual stereo channels with mixable A and B inputs featuring independent level control and
channel reverse
• A inputs switchable for line and RIAA phono sources
• 2 microphone inputs with vocal EQ, effect in/out and independent level control
• Balanced XLR main mix output with VCA master level control
• Booth output for local stereo monitoring
• EFFECT loop with silent FET switching to add external effects
• Link in and out connections for daisy chaining mixers, recording or booth output
• 3 Band +6/-26 asymmetric EQ with extended cut
• VCA PAN controls to adjust LR balance or for performance effect
• Ultra smooth gold contact dual rail conductive plastic VCA crossfader and channel faders
• All faders are VCA for noise free operation and have reverse and variable contour controls
• Rotatable TRANSFORM switches for stutter effects
• Removable face plate for fader servicing and user preferred transform switch positioning
• Advanced headphones cue system with cue/mix select, cue crossfader and large meters
• Sensible performance control layout makes it very easy to use
• Universal internal power supply for any worldwide mains voltage
Front and Rear Panel Layouts
AVIS: RISQUE DE CHOC ELECTRIQUE - NE PAS OUVRIR.
100 - 240V~
47-63Hz ~ 30W MAX
SERIAL No:
P R O T U R N T A B L I S T D J M I X E R
