ALLEN & HEATH XONE:DB4 User Manual

Allen & Heath 14 XONE:DB4 User Guide
MASTER SECTION
HEADPHONES OUTPUTS
Stereo 1/4” TRS jack and 3.5mm mini-jack. Plug in good
quality stereo headphones intended for DJ monitoring.
Use closed-ear headphones that provide maximum acous-
tic isolation when cueing your sources. We recommend
that you use high quality headphones rated between 30 to
100 ohms impedance. 8 ohm headphones are not recom-
mended as their very low impedance may cause damage to
the headphone amplifier.
7
CHANNEL FADER CURVE SELECT
Sets the response of the Channel Up faders. Choose a
setting that best suits the style of music you play.
8
7
8
9
CROSSFADER CURVE SELECT
Sets the response of the Crossfader curve, from dipped,
dipless, and fast-cut, better suited to scratching.
9

ALLEN & HEATH XONE:DB4 Specifications

General

Frequency range	22 - 22000 Hz
Channels quantity	4 channels
Digital sound processing	- bit
Number of EQ bands per channel	4
Line Signal-to-Noise Ratio (SNR)	104 dB
XLR out	2
Microphone in	Yes
Line inputs (RCA)	8
Headphone connectivity	3.5 mm/6.35 mm
USB 2.0 ports quantity	1
Product color	Black
Video capability	No

Weight and Dimensions

Depth	358 mm
Width	320 mm
Height	88 mm
Weight	5100 g
Package depth	260 mm
Package width	530 mm
Package height	470 mm
Package weight	8600 g
