ALLEN & HEATH XONE:DB4 User Manual

Allen & Heath 30 XONE:DB4 User Guide
PC DRIVER INSTALLATION
STOP!
BEFORE YOU CONNECT YOUR XONE:DB4 TO A COMPUTER PLEASE FOLLOW
THESE INSTRUCTIONS ON INSTALLING THE CORRECT DRIVERS FOR THE USB
SOUNDCARD.
CHECK www.XONE.co.uk/db4 FOR NEWS ON THE LATEST DRIVER VERSIONS
Software Installation (Windows XP, Vista and Windows 7)
Follow the procedure described below to install the USB audio and MIDI drivers:
1— Connect the XONE:DB4 to your mains electricity supply.
Do not connect the DB4 to the PC at this time.
2— Open the Drivers folder and run Setup.exe.
3— Select your preferred language
4— Select Install the driver
5— When prompted, connect the DB4 to
the PC with the USB lead.

ALLEN & HEATH XONE:DB4 Specifications

General

Frequency range	22 - 22000 Hz
Channels quantity	4 channels
Digital sound processing	- bit
Number of EQ bands per channel	4
Line Signal-to-Noise Ratio (SNR)	104 dB
XLR out	2
Microphone in	Yes
Line inputs (RCA)	8
Headphone connectivity	3.5 mm/6.35 mm
USB 2.0 ports quantity	1
Product color	Black
Video capability	No

Weight and Dimensions

Depth	358 mm
Width	320 mm
Height	88 mm
Weight	5100 g
Package depth	260 mm
Package width	530 mm
Package height	470 mm
Package weight	8600 g
