ALLEN & HEATH XONE DX User Manual

Allen & Heath User Guide for XONE:DX with Serato ITCH 1.6 65
SPECIFICATIONS
Dimensions and Weights
The console is fitted with rubber feet for desktop operation.
Width Height Depth Weight
Desktop 400 mm(15.8”) 50 mm(2.0”) 325 mm(12.8”) 4.6kg (10.1 lbs)
Packed 505 mm(19.9”) 140 mm(5.5”) 470 mm(18.5”) 6.0kg (13.2 lbs)
Frequency Response SC in to SC out
96kHz Sample Rate
10 Hz to 20kHz +0/-1.0dB
10 Hz to 30kHz +0/-3dB
THD + N Line In to Line Out +8 dBu < 0.008%
Maximum Output Level (Balanced) +14dBu
Maximum Output Level (Unbalanced) +8dBu
Maximum Input Level +9dBu
Dynamic Range Output 100dB
System Dynamic Range Line In to Line Out 94dB
Mic Sensitivity -50dBu to –30dBu
RIAA Input Sensitivity 7-48mV 1KHz/330pF
325.00
400.00
18.73
17.60
65.24
68.73

ALLEN & HEATH XONE DX Specifications

General

Brand	ALLEN & HEATH
Model	XONE DX
Category	DJ Equipment
Language	English
