1–4 Overview
Publication 1203–5.1 –– July, 1997
Figure 1.3
Typical Programmable Controller/SCANport Device Interconnection
SCANport
Communications
Module
PLC
.
.
.
1305*
Micro
Drive
1336 PLUS
Open Style
RIO
Adapter
Remote I/O Link
.
Other Remote I/O Devices
ÁÁÁ
ÁÁÁ
ÀÀ
ÀÀ
Panel View Operator Terminal
*NOTE: Refer to Page 1–1 for compatibility
requirements of SCANport devices
SCANport
Communications
Module
SMP 3
Communications
Module
SMC Dialog Plus
