2–10 Installation
Publication 1203–5.1 –– July, 1997
Figure 2.9
Open Style Communications Module Mounting Location (1336
FORCE Drive)
1336 FORCE Main Control Board
TB2
L OPTION
J4
Open Communications Module
Mounts Here
J1
Mounting Screws & Standoffs Qty 4
1336 FORCE Standard Adapter Board
SCANport 6
Install the board with the component side facing you.
"
