10 1734 POINT I/O EtherNet/IP Adapter
Publication 1734-IN042D-EN-P - October 2015
2. Press down firmly to install the adapter on a DIN rail, noting that the locking
mechanism locks the adapter to the DIN rail.
3. Set the network address thumbwheel switches to the desired value. See Set the
Network Address for more information on setting the IP address.
4. Slide the safety end cap up to remove it, exposing the backplane and power
interconnections.
ATTENTION: Do not discard the end cap. Use this end cap to cover the
exposed interconnections on the last mounting base on the DIN rail. Failure to
do so could result in equipment damage or injury from electric shock.
ATTENTION: This product is grounded through the DIN rail to chassis ground.
Use zinc plated yellow-chromate steel DIN rail to assure proper grounding. The
use of other DIN rail materials (for example, aluminum or plastic) that can
corrode, oxidize, or are poor conductors, can result in improper or intermittent
grounding. Secure DIN rail to mounting surface approximately every 200 mm
(7.8 in.) and use end-anchors appropriately.
ATTENTION: Allow 25.4 mm (1 in.) of space between adjacent equipment for
adequate ventilation.
WARNING: If you connect or disconnect the communications cable with
power applied to this module or any device on the network, an electrical arc
can occur. This could cause an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
ATTENTION: Do not remove or replace an Adapter Module while power is
applied. Interruption of the backplane can result in unintentional operation or
machine motion.
