20 1734 POINT I/O EtherNet/IP Adapter
Publication 1734-IN042D-EN-P - October 2015
Inrush current, max 6.0A for 10ms
Input overvoltage protection Reverse polarity protected
POINTBus output current, max 5V DC @ 1.0A
Interruption Output voltage will stay within specifications when input drops
out for 10ms at 10V with maximum load.
Ethernet Communication
Attribute Value
Ethernet communication rate 10/100 Mbits/s, half or full-duplex
Ethernet ports 1
Ethernet network topologies supported Star, Tree
Ethernet connector RJ-45, Category 5
Ethernet cable Category 5:
shielded or unshielded
Ethernet wire connections, max See Wire Size
on page 21.
General Specifications
Attribute Value
Indicators 3 red/green status indicators (on CPU):
– Module status
– Network status
– POINTBus status
1 green status indicator on CPU:
– Network activity
2 green power supply status indicators on DC-DC Converter:
– System power (5V DC to POINTBus Out)
– Field power (24V DC from Field In)
Power consumption, max 10.4 W @ 28.8V DC
Power dissipation, max 5.2 W @ 28.8V DC
Thermal dissipation, max 17.75 BTU/hr @ 28.8V DC
Isolation voltage 50V (continuous), Reinforced Insulation Type, between
all circuits.
Type tested at 500V AC for 60 s
Field power supply 10...28.8V DC @ 10A
Power Supply
Attribute Value
