1734 POINT I/O EtherNet/IP Adapter 21
Publication 1734-IN042D-EN-P - October 2015
Field power output 10...28.8V DC @ 9A
Module input 10...28V DC @ 1000 mA
POINTBus output, max 5V DC @ 1.0A
Dimensions (HxWxD), approx. 76.2 x 54.9 x 133.4 mm (3.0 x 2.16 x 5.25 in.)
Enclosure type rating None (open-style)
Terminal base screw torque 0.8 Nm (7 lb-in)
Weight, approx. 255 g (0.56 lb)
Wiring category
(1)
,
(2)
1 – on power ports
1 – on communications ports
Wire Size Power connections:
0.34... 2.1 mm
(22...14 AWG) solid or stranded copper wire
rated @ 75 °C (167 °F ) or greater, 1.2 mm (3/64 in.) insulation
max or 90
°C (194 °F ) for ControlLogix.
Ethernet wiring:
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category
5e min cable according to TIA 568-B.1 or Category 5 cable
according to ISO/IEC 24702.
North American temp code T4A
IEC Temp Code T4
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and
Grounding Guidelines, publication 1770-IN041.
(2)
Use the Conductor Category information for planning conductor routing as described in the appropriate System Level
Installation Manual.
Environmental Specifications
Attribute Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...55 °C (-4...131 °F)
Temperature, surrounding air, max 55 °C (131 °F)
Temperature, nonoperating IEC60068-2-1 (Test Ab, Unpackaged Nonoperating Cold)
IEC60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat)
IEC60068-2-14 (Test Na, Unpackaged Nonoperating
Thermal Shock):
-40...85 °C (-40...185 °F)
General Specifications
Attribute Value
