Allen-Bradley 1734-AENT User Manual

14 1734 POINT I/O EtherNet/IP Adapter
Publication 1734-IN042D-EN-P - October 2015
9. Press firmly to seat the adapter on the DIN rail, noting that the adapter locking
mechanism will snap into place.
10. Set the node address on the node address thumbwheel.
11. Insert the end of the terminal block opposite the handle into the base unit, noting
that this end has a curved section that engages with the wiring base.
12. Rotate the terminal block into the wiring base until it locks itself into place.
13. Replace the adjacent module in its base.
14. Reconnect the Ethernet cable(s) to the adapter.
15. Set the IP Address for this module.
16. Configure the adapter’s chassis size.
WARNING: When used in a Class I, Division 2, hazardous location, this
equipment must be mounted in a suitable enclosure with proper wiring method
that complies with the governing electrical codes.

Allen-Bradley 1734-AENT Specifications

General

Product Type	EtherNet/IP Adapter
Network Protocol	EtherNet/IP
Enclosure Type Rating	None (open-style)
Storage Temperature	-40 to 85 °C (-40 to 185 °F)
Housing Material	Plastic
Operating Temperature	0 to 55 °C (32 to 131 °F)
Current Draw @ 24V DC	100 mA maximum
Network Address	Configurable via software
Ports	1 Ethernet port
