18 POINT I/O 2 Current and 2 Voltage Input Analog Modules
Publication 1734-IN027C-EN-E - October 2016
(1)
Includes offset, gain, non-linearity, and repeatability error terms.
General Specifications
Attribute 1734-IE2C 1734-IE2V
Indicators, logic side 1 green/red – module status
1 green/red – network status
2 green/red – input status
Terminal base 1734-TB, 1734-TBS, 1734-TOP, or 1734-TOPS
POINTBus current, max 75 mA @ 5V DC
Power dissipation, max 0.6 W @ 28.8V DC 0.75 W @ 28.8V DC
Thermal dissipation, max 2.0 BTU/hr @ 28.8V DC 2.5 BTU/hr @ 28.8V DC
Isolation voltage 50V continuous
No isolation between individual
channels
Tested to withstand 2550V DC for
60s
50V continuous
No isolation between individual
channels
Tested to withstand 2200V DC for
60s
External DC power
Supply voltage, nom
Voltage range
Supply current
24V DC
10...28.8V DC
10 mA @ 24V DC
24V DC
10...28.8V DC
15 mA @ 24V DC
Dimensions, approx., HxWxD 56 x 12 x 75.5 mm
(2.21 x 0.47 x 2.97 in.)
Wiring category
(1)
1 – on signal ports
Wire size 0.25…2.5 mm
2
(22…14 AWG) solid or stranded shielded copper wire
rated at 75 °C (167 °F) or greater 1.2 mm (3/64 in.) insulation max
Weight, approx. 0.036 kg (0.08 lb)
Enclosure type rating None (open-style)
Keyswitch position 3
(1)
Use this conductor category information for planning conductor routing as described in Industrial Automation Wiring
and Grounding Guidelines, publication 1770-4.1
.
