POINT I/O 2 Current and 2 Voltage Input Analog Modules 11
Publication 1734-IN027D-EN-E - December 2018
3. Insert the module straight down into the mounting base and press to secure.
The module locks into place.
Turn the keyswitch to
align the number with
the notch. Notch
position 3 is shown.
Be sure the DIN-rail
locking screw is in the
horizontal position.
1734-TB Base
45696
Turn the keyswitch to
align the number with
the notch. Notch
position 1 is shown.
Be sure the DIN-rail
locking screw is in the
horizontal position.
1734-TOP Base
45697
Modu
l
e
St
at
u
s
Net
w
o
rk
Stat
u
s
NODE:
0
1
2
3
