Allen-Bradley 1734-IE2V

POINT I/O 2 Current and 2 Voltage Input Analog Modules 15
Publication 1734-IN027D-EN-E - December 2018
Wire the Module
POINT I/O 2 Current and 2 Voltage Output Analog Modules
WARNING: If you connect or disconnect wiring while the field-side power is
on, an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
Input 0
Chas gnd
C
Chas gnd
Input 1
41974
C
V
V
Chas gnd = Chassis ground
C = Common
V = Supply
CC
VV
1734
IE2V
Input 0
Chas gnd Chas gnd
Input 1
1734-IE2C, 1734-IE2CK 1734-IE2V, 1734-IE2VK
