Allen-Bradley 1734-IE2V

POINT I/O 2 Current and 2 Voltage Input Analog Modules 7
Publication 1734-IN027D-EN-E - December 2018
Before You Begin
Note that this series C product can be used with the following:
• DeviceNet® and PROFIBUS adapters
• ControlNet® and EtherNet/IP™ adapters, using RSLogix 5000® software, version
11 or later
See the figures to familiarize yourself with major parts of the module, noting that the
wiring base assembly is one of the following:
• 1734-TB or 1734-TBS POINT I/O™ two-piece terminal base, which includes
the 1734-RTB or 1734-RTBS removable terminal block, and 1734-MB
mounting base
• 1734-TOP or 1734-TOPS POINT I/O one-piece terminal base
POINT I/O Module with 1734-TB or 1734-TBS Base
Analog
Voltage
Output
Module
Status
Network
Status
NODE:
0
1
1
10
9
8
7
2
4
5
6
3
43930
