POINT I/O 2 Current and 2 Voltage Input Analog Modules 19
Publication 1734-IN027D-EN-E - December 2018
Network status Off Device is not online:
- Device has not completed dup_MAC-id test.
- Device not powered – check module status indicator.
Flashing green Device is online but has no connections in the established state.
Green Device is online and has connections in the established state.
Flashing red One or more I/O connections are in timed-out state.
Red Critical link failure – failed communication device. Device detected
error that prevents it from communicating on the network.
Flashing red/green Communication faulted device – the device has detected a
network access error and is in communication faulted state. Device
has received and accepted an Identity Communication Faulted
Request – long protocol message.
Channel status Off Module is in CAL mode.
Solid green Normal operation is present with channel scanning inputs.
Flashing green Channel is being calibrated.
Solid red Major channel fault is present.
Flashing red Channel is at end of range (0 mA or 21 mA) for 1734-IE2C,
1734-IE2CK.
Channel is at end of range (over or under) for 1734-IE2V,
1734-IE2VK.
Indicator Status for Modules
Status Description
