Appendix F I/O Assemblies
Output Assemblies
Analog Input Assemblies
Table 27 - 1734-OB8S Input Assemblies
Instance
Decimal (hex)
Connection
Type
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
580 (244 h) Safety and
Standard
0Safety Output 7
Status
Safety Output 6
Status
Safety Output
5 Status
Safety Output
4 Status
Safety Output
3 Status
Safety Output
2 Status
Safety Output
1 Status
Safety Output
0 Status
1028 (404 h) Safety and
Standard
0Safety Output 7
Status
Safety Output 6
Status
Safety Output
5 Status
Safety Output
4 Status
Safety Output
3 Status
Safety Output
2 Status
Safety Output
1 Status
Safety Output
0 Status
1Safety Output
Monitor 7
Safety Output
Monitor 6
Safety Output
Monitor 5
Safety Output
Monitor 4
Safety Output
Monitor 3
Safety Output
Monitor 2
Safety Output
Monitor 1
Safety Output
Monitor 0
1044 (414 h) Safety and
Standard
0Safety Output
Monitor 7
Safety Output
Monitor 6
Safety Output
Monitor 5
Safety Output
Monitor 4
Safety Output
Monitor 3
Safety Output
Monitor 2
Safety Output
Monitor 1
Safety Output
Monitor 0
1 Reserved Combined
Output Status
Reserved Output Power
Error
(1)
Reserved
(1) This data is diagnostic only and does not have safety integrity.
Table 28 - 1734-OBV2S Input Assemblies
Instance
Decimal (hex)
Connection
Type
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
579 (243 h) Safety 0 Reserved Reserved Reserved Reserved Safety Output
3 Status
Safety Output
2 Status
Safety Output
1 Status
Safety Output
0 Status
1027 (403 h) Safety and
Standard
0Safety Output 3
Readback
Safety Output 2
Readback
Safety Output
1 Readback
Safety Output
0 Readback
Safety Output
3 Status
Safety Output
2 Status
Safety Output
1 Status
Safety Output
0 Status
1043 (413 h) Safety and
Standard
0 Reserved Reserved Reserved Reserved Safety Output
3 Readback
Safety Output
2 Readback
Safety Output
1 Readback
Safety Output
0 Readback
1 Reserved Combined
Output Status
Reserved Output Power
Error
(1)
Reserved
(1) This data is diagnostic only and does not have safety integrity.
Table 29 - Output Assemblies for all POINT Guard I/O™ Modules
Instance Decimal
(hex)
Module Connection
Type
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
33 (21 h) 1734-IB8S Safety
(1)
0
Reserved
Standard
Output 3
Standard
Output 2
Standard
Output 1
Standard
Output 0
564 (234 h) 1734-OB8S Safety Only 0 Safety
Output 7
Safety
Output 6
Safety
Output 5
Safety
Output 4
Safety
Output 3
Safety
Output 2
Safety
Output 1
Safety
Output 0
563 (233 h) 1734-OBV2S Safety Only 0 Reserved Reserved Reserved Reserved Safety
Output 3
Safety
Output 2
Safety
Output 1
Safety
Output 0
770 (302 h) 1734-IE4S Safety 0 Reserved Reserved Reserved Reserved Reset Tach
3
(2)
Reset Tach
2
(2)
Reset Tach
1
(2)
Reset Tach
0
(2)
(1) Only outputs 1 and 3 are configurable to Muting or Test Outputs. This assembly is accessible only over a Safety connection.
(2) When set (1), this bit specifies a reset of an overfrequency condition on the tachometer counter. Clear this bit to allow the tachometer channel to operate.
Table 30 - 1734-IE4S Input Assemblies
Instance
Decimal (hex)
Connection
Type
Byte High Byte Low Byte
