Rockwell Automation Publication IASIMP-QS023B-EN-P - December 2012 63
Chapter 5
Create a Logix Designer Project
In this chapter you create a Logix Designer project. In the project you use ladder logic to create a
push button that controls a light on a digital output module.
You learn how to complete the following tasks:
• Create a Logix Designer project
• Configure your 1769-L36ERM controller
• Add a local expansion module to the project
• Add a 1769-SDN scanner module to the project
• Add ladder logic to the project to test the local expansion module
• Download the project to the controller
You must use the Logix Designer application with this quick start. The tasks in this chapter are described with the
intention that you might reuse the project to complete tasks described in publications listed on page 12
.
For example, you are not required to add a 1769-SDN scanner module to your project to use ladder logic to test the local
expansion module. The tasks to add the scanner module are described so you can easily use the project from this quick
start with one of the publications listed on page 12 related to using a DeviceNet network.
