Allen-Bradley 1784-KT/B User Manual

Communication Interface Module
Cat. No. 1784KT/B
Installation Data
4
Operation of the 1784-KT has been verified with the following:
Company: Model:
AllenBradley
• 1771 Information Processor
(1771DSX2) (requires KT Expander
Module 1771DXKT)
• 1784T35 Industrial Terminal
• 1784T50 Industrial Terminal
• AllenBradley 6121
• AllenBradley 6122
• T53 Industrial Programming Terminal
6160T53
• T60 Industrial Workstation
6160PCD2, PCN2, PCD4, PCN4
• T70 Industrial Workstation
6170 series
IBM

• IBM PCXT/AT
Compaq

• Compaq Portable 286
• Compaq Portable II
• Compaq Portable III
• Compaq Deskpro 286
• Compaq Deskpro 386
Dell

• Dell 316 386SX
Samsung
• Samsung S550
• Samsung 386
HewlettPackard

• HP 9000/700 series
The 1784-KT allows you to:
directly connect to:
- PLC-2 processors
- PLC-3 processors
communicate with nodes on Data Highway Plus networks (including
PLC-5 and PLC-5/250 processors)
communicate with SLC processors (requires 1785-KA5 bridge)
The 1784-KT performs data transmission, management, and local Data
Highway Plus diagnostics. The interface to the host processor is through a
board-resident dual-port memory that passes preformatted Data Highway
Plus packets.
When the host powers up and downloads module code, it runs diagnostics
to verify the 1784-KT module’s operation. Allen-Bradley interface
software (including 6001-F1E, 6200, Interchange, Advisor PC, and
ControlView) manages data transmission and reception through the
board-resident dual-port memory.
Compatibility
How
the 1784KT Operates
