12 FLEX I/O Isolated Output HART Analog Module
Publication 1794-IN120D-EN-P - September 2015
Output Map
Word Bit
1514131211109876543210
0 R GR R R R R R R DG7 DG6 DG5 DG4 DG3 DG2 DG1 DG0
1 Channel 0 Output Data
2 Channel 1 Output Data
3 Channel 2 Output Data
4 Channel 3 Output Data
5 Channel 4 Output Data
6 Channel 5 Output Data
7 Channel 6 Output Data
8 Channel 7 Output Data
DGn =
GR =
R =
Channel n Digital Output Data. Valid in Digital mode only.
Global reset. Resets all latched wire fault alarms.
Reserved
0 = Output 0 mA
(1)
;
1 = Output 22 mA
0 = Inactive; 1 = Active
(1)
When Open Wire Detect is Enabled, 0 = 100 μA on Output
Note: Reserved data may not be shown in certain controller software
To Next Page
