86 Rockwell Automation Publication 2080-UM004C-EN-E - March 2015
Appendix B Quickstart
4. The Connection Browser dialog appears, select the 2080-DNET20 plug-
in and click OK.
5. Select the firmware revision to flash and click Next.
To upgrade from firmware revision 1.012 to 2.011, the DeviceNet
network should be used. From revision 2.011 onwards, you can upgrade
the firmware using the controller pass through feature.
