Rockwell Automation Publication 2080-UM004C-EN-E - March 2015 105
Appendix
C
Error Codes
Troubleshooting
For troubleshooting your Micro800 controller system, see the User Manual for
your controller:
• Micro830 and Micro850 Programmable Controllers User Manual,
publication 2080-UM002
.
• Micro820 Programmable Controllers User Manual, publication
2080-UM005
.
Error Codes for Micro800
Plug-ins
This section lists possible error codes for your plug-in modules, as well as
recommended actions for recovery.
If an error persists after performing the recommended action, contact your local
Rockwell Automation technical support representative. For contact information,
go to http://support.rockwellautomation.com/MySupport.asp
List of Error Codes for Micro800 Plug-ins
Error Code Description Recommended Action
For the following four error codes, z refers to the slot number of the plug-in module. If z = 0, then the slot number cannot be identified
0xF0Az The plug-in I/O module has encountered an error
during operation.
Perform one of the following:
• Check the condition and operation of the plug-in I/O module.
• Cycle power to the Micro800 controller.
0xF0Bz The plug-in I/O module configuration does not
match the actual I/O configuration detected.
Perform one of the following:
• Correct the plug-in I/O module configuration in the user program to match
that of the actual hardware configuration.
• Check the condition and operation of the plug-in I/O module.
• Cycle power to the Micro800 controller.
• Replace the plug-in I/O module.
0xF0Dz A hardware error has occurred while power was
being applied to the plug-in module or the plug-in
module was removed.
Perform the following:
• Correct the plug-in I/O module configuration in the user program.
• Build and download the program using Connected Components Workbench.
• Put the Micro800 controller into Run mode.
0xF0Ez The plug-in I/O module configuration does not
match the actual I/O configuration detected.
Perform the following:
• Correct the plug-in I/O module configuration in the user program.
• Build and download the program using Connected Components Workbench.
• Put the Micro800 controller into Run mode.
