Allen-Bradley 2080-IF4 - DeviceNet Address and Baud Rate Settings

Rockwell Automation Publication 2080-UM004C-EN-E - March 2015 41
DeviceNet Plug-in – 2080-DNET20 Appendix 5
DeviceNet Switches
2080-DNET20 Assembly Diagram
IMPORTANT
Maximum power supply drop cable length is 3 m.
TIP
Recommended Cable
Flat Cable (Kwiklink lite)
– Class 1 cable maximum allowable current 8A (NEC/CECode)
– Class 2 cable maximum allowable current 4A (NEC/CECode)
ON
1
23
4
5
7
6
8
Dim A
Pos. 1 Designate
Pin #1 Location
1
35
7 9 11 13
15
2
4
6
8
10 12
14
16
CONTACT CONFIGURATION
(Pos. 1 denotes Pin # 1)
DeviceNet Address (MAC_ID) Switch Definitions
Node Address SW1 Switch Positions
345678
Switch Position Values
32168421
0 (default) OFF OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF OFF ON
2 OFF OFF OFF OFF ON OFF
3 OFF OFF OFF OFF ON ON
4 OFF OFF OFF ON OFF OFF
5 OFF OFF OFF ON OFF ON
…
62 ON ON ON ON ON OFF
63 ON ON ON ON ON ON
