Allen-Bradley 2080-IF4 - Appendix A; Digital Plug-In Modules

Rockwell Automation Publication 2080-UM004C-EN-E - March 2015 59
Appendix A
Specifications
Digital Plug-in Modules
General Specifications – 2080-OB4, 2080-OV4, 2080-IQ4OB4, 2080-IQ4OV4, 2080-IQ4
Attribute Value
Mounting torque 0.2 Nm (1.48 lb-in.)
Status indicators For input or output modules – 4 yellow
For combination modules – 8 yellow
Terminal base screw torque 0.22…0.25 Nm (1.95…2.21 lb-in.)
using a 2.5 mm (0.10 in.) flat-blade screwdriver
Enclosure type rating None (open-style)
Isolation voltage For input modules
50V (continuous), Basic Insulation Type, Inputs to Backplane
Type tested for 60 s @ 720 V DC, Inputs to Backplane
For combination or output modules
50V (continuous), Basic Insulation Type, Inputs to Outputs, I/Os
to Backplane
Type tested for 60 s @ 720 V DC, I/Os to Backplane
Wire size 1.3... 0.2 mm
2
(16...24 AWG) solid or stranded copper wire
rated @ 90 °C (194 °F), or greater, insulation max
Wire category 2 – on signal ports
2 – on power ports
North American temp code T4
Input Specifications – 2080-IQ4, 2080-IQ4OV4, 2080-IQ4OB4
Attribute Value
DC on-state voltage, min 9.0V DC
DC on-state voltage, max 30V DC
DC on-state current, min 2.0 mA @ 9V DC
DC on-state current, nom 3.0 mA @ 24V DC
DC on-state current, max 5.0 mA
DC off-state voltage, max 5V DC
DC off-state current, max 1.5 mA
IEC input compatibility Type 3
Input impedance 0…3V, >4 KΩ
3…12V, 3.5 KΩ min
12…30V, >4 KΩ <10 KΩ
Input filter time ON to OFF 8…10 ms AC/DC
AC on-state voltage, min 10.25V AC (rms)
AC on-state voltage, max 30V AC (rms)
