14 1732E ArmorBlock 2 Port Ethernet Module
Publication
1732E-IN004A-EN-E - November 2009
Network status Off The device is not initialized or the module does not
have an IP address.
Flashing green The device has no CIP connections.
The device has an IP address, but no CIP connections
are established.
Green The device is online, has an IP address, and CIP
connections are established.
Flashing red One or more connections have timed out.
Red The module has detected that its IP address is
already in use.
Flashing red/green The module is performing a powerup self-test.
Network link status Off No link established.
Green Link established on indicated port at 100 Mbps.
Flashing green Link activity present on indicated port at 100 Mbps.
Yellow Link established on indicated port at 10 Mbps.
Flashing yellow Link activity present on indicated port at 10 Mbps.
Auxiliary status Off No auxiliary power to device or input not valid.
Green Auxiliary power applied to device.
Digital output status
(1)
Off Output not energized.
Yellow Output energized.
Red Output shorted.
Flashing red Output open load.
Digital input status
(1)
Off No valid input.
Yellow Valid input.
Red Sensor source voltage shorted.
Flashing red Sensor source open wire.
(1)
Only diagnostic modules 1732E-*DR have red I/O status LEDs.
IMPORTANT
The Module Status LED indicator will flash red and green for a maximum
30 s while the module completes its POST (Power-On Self Test).
Indicator Status for Modules
Status Description
