1732E ArmorBlock 2 Port Ethernet Module 15
Publication
1732E-IN004A-EN-E - November 2009
Specifications
ArmorBlock 2 Port Ethernet Module Input – 1732E-8X8M12DR, 1732E-IB16M12R,
1732E-IB16M12DR, 1732E-IB16M12SOEDR, 1732E-16CFGM12R
Attributes Value
Number of inputs 8 – 1732E-8X8M12DR
16 – all other modules
Input type Sink, 24V DC
Voltage, off-state input, max 5V DC
Voltage, on-state input, max 30V DC
Voltage, on-state input, nom 24V DC
Voltage, on-state input, min 11V DC
Current, off-state input, max 1.5 mA @ 5V DC
Current, on-state input, max 5 mA @ 30V DC
Voltage, sensor source, max 30V DC
Voltage, sensor source, min 10V DC
Input delay time
ON to OFF
OFF to ON
0…16000 μs
Isolation voltage 50V (continuous), Basic Insulation Type, Inputs and Sensor Power to
Network
No isolation between individual Inputs or between Network channels
Type tested at 707V DC for 60s
ArmorBlock 2 Port Ethernet Module Output – 1732E-8X8M12DR,
1732E-OB16M12R, 1732E-OB16M12DR, 1732E-16CFGM12R
Attributes Value
Number of outputs 8 – 1732E-8X8M12DR
16 – all other modules
Output type Source, 24V DC
Voltage drop, on-state output,
max
0.5V DC
Voltage off-peak blocking, min 30V DC
Voltage, on-state output, max 30V DC
