16 1732E ArmorBlock 2 Port Ethernet Module
Publication
1732E-IN004A-EN-E - November 2009
Voltage, on-state output, min 11V DC
Voltage, on-state output, nom 24V DC
Current on-state output, max 2 A – 1732E-OB16M12R
0.5 A – all other modules
Current per module, max 4.0 A – 1732E-8X8M12DR
8.0 A – all other modules
Leakage current, off-state
output, max
50 μA
Surge current per output, max 4.8 A for 10 ms, repeatable every 2 s – 1732E-OB16M12R
1.2 A for 10 ms, repeatable every 2 s – all other modules
Isolation voltage 50V (continuous), Basic Insulation Type, Outputs and Output Power to
Network
No isolation between individual Outputs or between Outputs and
Output power or between Network channels
Type tested at 707V DC for 60s
Pilot duty rating DC-14
General Specifications
Attributes Value
Voltage, auxiliary power, max 30V DC
Voltage, auxiliary power, min 12V DC
Current, Ethernet system power, max
(pins 2, 3 sensor source/module power)
0.4 A – 1732E-OB16M12R, 1732E-OB16M12DR
0.8 A – 1732E-8X8M12DR
1.2 A – 1732E-IB16M12R, 1732E-IB16M12DR,
1732E-IB16M12SOEDR, 1732E-16CFGM12R
Current, auxiliary power, max per output module
(pins 2, 3 sensor source/module power plus
pins 1, 4 for output loads)
4 A – 1732E-8X8M12DR
8 A – all other modules
Current, sensor source, per input, max 50 mA
Current, sensor source, per connector, max 100 mA
Communication rate EtherNet/IP
10/100 Mbps
Full or half-duplex
100 meter per segment
ArmorBlock 2 Port Ethernet Module Output – 1732E-8X8M12DR,
1732E-OB16M12R, 1732E-OB16M12DR, 1732E-16CFGM12R
Attributes Value
