Rockwell Automation Publication IASIMP-QS024C-EN-P - August 2014 53
Create a Logix Designer Project Chapter 4
11. Use the tabs on the Controller Properties
dialog box to configure the controller.
The IP address is set on the Internet
Protocol tab.
There are many configurable parameters on
various tabs in the Controller Properties
dialog box. For more information on
configuring your CompactLogix 5370 L1 controller, see the CompactLogix 5370 Controllers User Manual,
publication 1769-UM021
.
12. Click OK.
13. Click Yes to apply changes.
14. Go offline.
Make sure you set an IP Address
and Subnet Mask that matches
the values set in Set the IP
Address for the Computer on
page 35.
