Allen-Bradley ControlLogix 1756-IF4FXOF2F User Manual

12 ControlLogix High Speed Analog I/O Module
Publication
1756-IN004A-EN-P - February 2002
After completing field-side wiring, secure the wires in the strain relief
area with a cable-tie.
12
34
56
78
910
1112
1314
1516
1718
1920
2122
2324
2526
2728
2930
3132
3334
3536
1756-IF4FXOF2F Voltage Mode Wiring Diagram
User
Analog
Input
Device
(+)
(-)
42743
Shield
ground
(+)
(+)
(-)
Shield
ground
+IN-1/V
IN-1/I
-IN-1
+IN-3/V
V OUT-1
IN-3/I
-IN-3
Not used
Not used
I OUT-1
RTN-1
Not used
+IN-0/V
IN-0/I
-IN-0
+IN-2/V
IN-2/I
-IN-2
Not used
Not used
Not used
Not used
Not used
Not used
V OUT-0
Not used
Not used
I OUT-0
Not used
Not used
Not used
Not used
Not used
Not used
Not used
RTN-0
