Allen-Bradley ControlLogix 1756-IF4FXOF2F - 1756-IF4 FXOF2 F Specifications; General Module Specifications; Environmental Conditions

16 ControlLogix High Speed Analog I/O Module
Publication
1756-IN004A-EN-P - February 2002
1756-IF4FXOF2F Specifications
General Module Specifications
Module Location 1756 ControlLogix chassis
Backplane Current
(No module external
power requirements)
375mA @ 5.1V dc & 100mA @ 24V dc
(Total backplane power = 4.3W)
PowerDissipation within Module
Thermal Dissipation
4.3W voltage
4.7W current
14.66 BTU/hr voltage
16.02 BTU/hr current
Data Format Floating point IEEE 32 bit
Isolation Voltage
Field side to system side
Optoisolated, transformer isolated
100% tested at 2550V dc for 1s
RTB Screw Torque (NEMA) 7-9 inch-pounds (0.8-1Nm)
Module Keying (Backplane) Electronic
RTB Keying User defined
Field Wiring Arm and Housing
36 Position RTB (1756-TBCH or TBS6H)
(1)
Conductors Wire Size
Category
22-14 gauge (2mm
2
) stranded
(2)
3/64 inch (1.2mm) insulation maximum
2
(2)
Screwdriver Width for RTB 5/16 inch (8mm) maximum
Environmental Conditions
Operating Temperature IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
0 to 60°C (32 to 140°F)
Storage Temperature IEC 60068-2-1 (Test Ab, Un-packaged Non-operating
Cold)
IEC 60068-2-2 (Test Bc, Un-packaged Non-operating
Dry Heat)
IEC 60068-2-14 (Test Na, Un-packaged Non-operating
Thermal
–40 to 85°C (–40 to 185°F)
Relative Humidity IEC 60068-2-30 (Test Db, Un-packaged Non-operating
Damp Heat)
5 to 95% non-condensing
Vibration IEC60068-2-6 (Test Fc, Operating)
2g @ 10-500Hz
