Module Configuration Attributes
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 483
• "Light" Duty provides highest continuous rating at the expense of lower
overload capacity.
Specification for the continuous and overload ratings under Normal, Heavy, and
Light Duty are left to the discretion of the drive vendor.
Duty Select is used to determine the level of thermal protection for the motor and
the inverter during drive operation.
Converter AC Input Phasing
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set
USINT 0 - - Enumeration:
0 = Three-Phase (R)
1 = Single-Phase (O)
2-255 = (reserved)
This attribute indicates whether the converter input power to AC line is
Single-Phase or Three-Phase.
Converter AC Input Voltage
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set
UINT 230 0
Volts (RMS)
This value configures the drive for the intended AC line voltage applied to the
converter.
Demonstration Mode Select
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set
USINT 0 0 1 Enumeration:
0 = Inactive
1 = Active
2-255 = (reserved)
Activating Demonstration Mode, or 'Demo Mode', allows the associated converter
and inverter power structures to operate using Single-Phase, 110/120 VAC,
50/60Hz, AC line input. Converter and inverter performance is significantly
limited as compared to standard operation with Demo Mode inactive. All
converter and inverter modules in a shared DC bus configuration should have the
same Demo Mode setting to avoid faulting.
