16 Micro820 20-Point Programmable Controllers
Publication 2080-IN009B-EN-P - April 2014
Output circuit type Relay 24V DC source
(standard and high-speed)
Relay
Power input 24V DC
Power consumption 5.62 W (without plug-ins, max)…8.5 W (with plug-ins, max)
Power dissipation 6 W
Power supply
voltage range
20.4…26.4 V DC, Class 2, or
Limited Voltage Limited Current Source (LVLC)
Auxiliary power
supply output for
thermistor
10V
I/O rating Input: 120V AC 16 mA
O u t p u t : 2 A , 2 4 0 V A C
2A, 24V DC
Input: 24V DC, 8.8 mA
Output: 24V DC, 1 A per
point
(Surrounding air
t e m p e r a t u r e 3 0 ° C )
24 V DC, 0.3 A per point
(Surrounding air
temperature 65 °C)
Input: 24V DC, 8.8 mA
Output: 2 A,
240 V AC, 2A, 24V DC
Isolation voltage 250V (continuous),
Reinforced Insulation Type,
Output to Aux and
Network, Inputs to Outputs.
150V (continuous),
Reinforced Insulation Type,
Input to Aux and Network.
Type tested for 60 s @
3250 V DC Output to Aux
and Network, Inputs to
Outputs.
Type tested for 60 s @
1950 V DC Input to Aux and
Network.
50V (continuous),
Reinforced Insulation
Type, I/O to Aux and
Network, Inputs to
Outputs.
Type tested for 60 s @
720 V DC, I/O to Aux and
Network, Inputs to
Outputs.
250V (continuous),
Reinforced Insulation Type,
Output to Aux and
Network, Inputs to
Outputs.
50V (continuous),
Reinforced Insulation Type,
Input to Aux and Network.
Type tested for 60 s @ 720
V DC, Inputs to Aux and
Network, 3250 V DC
Outputs to Aux and
Network, Inputs to
Outputs.
Pilot duty rating C300, R150 – C300, R150
Insulation stripping
length
• 7 mm for the removable and fixed terminal blocks
• 5 mm for the RS232/RS485 serial port
Enclosure type rating Meets IP20
North American
temp code
T4
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation
Wiring and Grounding Guidelines, publication 1770-4.1
.
General Specifications
Attribute 2080-LC20-20AWB(R) 2080-LC20-20QBB(R) 2080-LC20-20QWB(R)
