6 Micro820 20-Point Programmable Controllers
Publication 2080-IN009B-EN-P - April 2014
Additional Resources
If you would like a manual, you can:
• download a free electronic version from the Internet:
http://rockwellautomation.com/literature
• purchase a printed manual by contacting your local Allen-Bradley distributor or
Rockwell Automation representative
ATTENTION:
• To comply with the CE Low Voltage Directive (LVD), this equipment must be
powered from a source compliant with the following: Safety Extra Low
Voltage (SELV) or Protected Extra Low Voltage (PELV).
• To comply with UL restrictions, this equipment must be powered from a
Class 2 or Limited Voltage Limited Current Source (LVLC).
• For Class I Division 2 applications, use only Class I Division 2 listed or
recognized accessories and modules approved for use within the Micro800
®
platform.
ATTENTION:
• Electrostatic discharge can damage semiconductor devices inside the
module. Do not touch the connector pins or other sensitive area pins.
• Be careful when stripping wires. Wire fragments that fall into the controller
could cause damage. Once wiring is complete, make sure the controller is
free of all metal fragments.
• Do not connect directly to line voltage. Line voltage must be supplied by a
suitable, approved isolating transformer or power supply having short
circuit capacity not exceeding 100 VA maximum equivalent.
Resource Description
Micro820™ 20-point Programmable
Controllers User Manual, publication
2080-UM005
A more detailed description of how to install and use your
Micro820 programmable controller.
Micro800
®
Plug-in Modules User Manual,
publication 2080-UM004
Installation and wiring descriptions for the different Micro800
plug-in modules.
Micro800 AC Power Supply Installation
Instructions, publication 2080-IN001
Information on wiring and installing the optional AC power supply.
Micro820 Remote LCD Installation
Instructions, publication 2080-IN010
Information on wiring and installing the Micro800 Remote LCD,
2080-REMLCD.
Industrial Automation Wiring and
Grounding Guidelines, publication 1770-4.1
More information on proper wiring and grounding techniques.
