18 Micro820 20-Point Programmable Controllers
Publication 2080-IN009B-EN-P - April 2014
DC Input Specifications
Attribute Non-isolated, shared with
analog inputs (Inputs 00…03)
Isolated inputs
(Inputs 04…11) – for
2080-LC20-20QWB(R),
2080-LC20-20QBB(R) only
Voltage category 24V DC Sink 24V DC Sink/Source
On-state voltage, nom 12/24V DC 24V DC
On-state voltage range 9.8…26.4V DC 24V DC, nom
10…26.4V DC @ 65 °C (149 °F)
10…30V DC @ 30 °C (86 °F)
Off-state voltage, max 5V DC
Off-state current. max 0.5 mA 1.5 mA
On-state current, min 0.75 mA @ 10.8V DC
1.0 mA @ 15V DC
1.8 mA @ 10.8V DC
2.7 mA @ 15V DC
On-state current, nom 2.1 mA @ 24V DC 8.5 mA @24V DC
On-state current, max 2.6 mA @ 26.4V 12.0 mA @ 30V DC
Nominal impedance 14.1 kΩ (non-isolated) 3.74 kΩ (isolated)
IEC input compatibility Type 1 Type 3
Relay Output Specifications for O-00...06 for 2080-LC20-20QWB(R),
2080-LC20-20AWB(R)
Attribute Value
Voltage, min 5 V, AC
5 V, DC
Voltage, max 250 V, AC
Maximum switching time 10 ms, turn on
10 ms, turn off
Life 10,000,000 cycles (mechanical)
100,000 cycles (Electrical with UL test load)
