Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 89
Motion Control Chapter 7
General Rules for the Motion Control Function Blocks
To work with motion control function blocks, users need to be familiar with the
following general rules.
ATTENTION: Each motion function block has a set of variable inputs and
outputs that allows you to control a specific motion instruction. Refer to
the Connected Components Workbench Online Help for a description of
these variable inputs and outputs.
General Rules for the Motion Function Block
Parameter General Rules
Input parameters When Execute is True: The parameters are used with the rising edge of the Execute input. To modify any parameter, it
is necessary to change the input parameter(s) and to trigger motion again.
When Enable is True: The parameters are used with the rising edge of the Enable input and can be modified
continuously.
Inputs exceeding application
limits
If a function block is configured with parameters that result in a violation of application limits, the instance of the function
block generates an error. The Error output will be flagged On, and error information will be indicated by the output ErrorID.
The controller, in most cases, will remain in Run mode, and no motion error will be reported as a major controller fault.
Position/Distance Input For MC_MoveAbsolute function block, the position input is the absolute location commanded to the axis. For
MC_MoveRelative, the distance input is the relative location (considering current axis position is 0) from current position.
Velocity Input Velocity can be a signed value. Users are advised to use positive velocity.
Direction input for the MC_MoveVelocity function block can be used to define the direction of the move (that is, negative
velocity x negative direction = positive velocity).
For MC_MoveRelative and MC_MoveAbsolute function blocks the absolute value of the velocity is used.
Velocity input does not need to be reached if Jerk input is equal to 0.
Direction Input For MC_MoveAbsolute, direction input is ignored. (This is reserved for future use.)
For MC_MoveVelocity, direction input value can be 1 (positive direction), 0 (current direction) or -1 (negative direction).
For any other value, only the sign is taken into consideration. For example, -3 denotes negative direction, +2 denotes
positive direction, and so on.
For MC_MoveVelocity, the resulting sign of the product value derived from velocity x direction decides the motion
direction, if the value is not 0. For example, if velocity x direction = +300, then direction is positive.
Acceleration, Deceleration,
and Jerk Inputs
• Deceleration or Acceleration inputs should have a positive value. If Deceleration or Acceleration is set to be a
non-positive value, an error will be reported (Error ID: MC_FB_ERR_RANGE).
• The Jerk input should have a non-negative value. If Jerk is set to be a negative value, error will be reported.
(Error ID: MC_FB_ERR_RANGE).
• If maximum Jerk is configured as zero in Connected Components Workbench motion configuration, all jerk parameters
for the motion function block has to be configured as zero. Otherwise, the function block reports an error (Error ID:
MC_FB_ERR_RANGE).
• If Jerk is set as a non-zero value, S-Curve profile is generated. If Jerk is set as zero, trapezoidal profile is generated.
• If the motion engine fails to generate the motion profile prescribed by the dynamic input parameters, the function block
reports an error (Error ID: MC_FB_ERR_PROFILE).
See Function Block and Axis Status Error Codes
on page 106 for more information about error codes.
