Appendix A Specifications
For the Micro853 controller relay chart, see Relay Chart for Micro830,
Micro850, and Micro870 Controllers on page 234.
Micro830 24-Point Controllers
Load current, min 10 mA 10 mA 10 mA
Load current, max 2.0 A 100 mA (high-speed operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard operation)
Surge current, per point Refer to Relay Contacts Ratings on
page 214
4.0 A every 1 s @ 30 °C; every 2 s @ 65 °C
(1)
Current, per common, max 5 A — —
Turn on time/
Turn off time, max
10 ms 2.5 µs ON: 0.1 ms
OFF: 1 ms
(1) Applies for general purpose operation only. Does not apply for high-speed operation.
Outputs
Attribute 2080-LC30-16AWB,
2080-LC30-16QWB
2080-LC30-16QVB
Relay Output Hi-Speed Output
(Outputs 0…1)
Standard Output
(Outputs 2…5)
Relay Contacts Ratings
Maximum Volts Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A 2.0 A 1800V A 180V A
240V AC 7.5 A 0.75 A
24V DC 1.0 A 1.0 A 28V A
125V DC 0.22 A
General Specifications
Attribute 2080-LC30-24QWB 2080-LC30-24QVB 2080-LC30-24QBB
Number of I/O 24 (14 inputs, 10 outputs)
Dimensions (HxWxD) 90 x 150 x 80 mm (3.54 x 5.91 x 3.15 in.)
Shipping weight, approx. 0.423 kg (0.933 lb)
Wire size 0.2…2.5 mm
2
(24…14 AWG) solid copper wire or
0.2…2.5 mm
2
(24…14 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use Copper Conductors only
Terminal screw torque, max 0.6 Nm (4.4 lb-in)
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
