Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 215
Specifications Appendix A
Input circuit type 12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay 24V DC sink
(standard and high-speed)
24V DC source
(standard and high-speed)
Event input interrupt support Yes
Power consumption, max 8 W – without plug-in modules
12.32 W – with plug-in modules
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating Input:
24V DC, 8.8 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
24V DC, Class 2, 1 A per point (Surrounding air temperature 30 °C)
24 V DC, Class 2, 0.3 A per point (Surrounding air temperature 65 °C)
Isolation voltage 250V (continuous), Reinforced
Insulation Type, Outputs to Aux and
Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, Inputs
to Aux and Network, 3250 V DC
Outputs to Aux and Network, Inputs to
Outputs
50V (continuous), Reinforced Insulation Type, I/O to Aux and Network, Inputs to
Outputs
Type tested for 60 s @ 720V DC, I/O to Aux and Network, Inputs to Outputs
Pilot duty rating C300, R150 (2080-LC30-24QWB only) —
Insulation stripping length 7 mm (0.28 in.)
Enclosure type rating Meets IP20
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
General Specifications
Attribute 2080-LC30-24QWB 2080-LC30-24QVB 2080-LC30-24QBB
Inputs
Attribute 2080-LC30-24QWB, 2080-LC30-24QVB, 2080-LC30-24QBB
High-Speed DC Input
(Inputs 0…7)
Standard DC Input
(Inputs 8 and higher)
Number of Inputs 8 6
Voltage category 24V DC sink/source
Operating voltage range 16.8…26.4V DC 10…26.4V DC
Off-state voltage, max 5V DC
Off-state current, max 1.5 mA
On-state current, min 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 8.8 mA @ 24V DC 8.5 mA @ 24V DC
On-state current, max 12.0 mA @ 30V DC
Nominal impedance 3 kΩ 3.74 kΩ
IEC input compatibility Type 3
AC input filter setting 8 ms for all embedded inputs
(In Connected Components Workbench software, go to the
Embedded I/O configuration window to re-configure the filter
setting for each input group)
