Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 213
Specifications Appendix A
Inputs
Attribute 2080-LC30-16AWB 2080-LC30-16QVB, 2080-LC30-16QWB
120V AC Input High-Speed DC Input
(Inputs 0…3)
Standard DC Input
(Inputs 4…9)
Number of Inputs 10 4 6
Input group to backplane
isolation
Verified by the following dielectric
tests: 1,400V AC for 2 s
132V working voltage (IEC Class 2
reinforced insulation)
Verified by the following dielectric tests: 1,414V DC for 2 s
75V DC working voltage (IEC Class 2 reinforced insulation)
Voltage category 110V AC 24V DC sink/source
On-state voltage range 79…132V AC
47…63 Hz
16.8…26.4V DC 10…26.4V DC
Off-state voltage, max 20V AC 5V DC
Off-state current, max 1.5 mA
On-state current, min 5 mA @ 79V AC 5.0 mA @ 16.8V DC 1.8 mA @ 10V DC
On-state current, nom 12 mA @ 120V AC 7.66 mA @ 24V 6.15 mA @ 24V
On-state current, max 16 mA @ 132V AC 12.0 mA @ 30V DC
Nominal impedance 12 kΩ @ 50 Hz
10 kΩ @ 60 Hz
3 kΩ 3.74 kΩ
Inrush current, max 250 mA @ 120V AC —
Turn on time/
Turn off time, max
(without filtering)
ON: 1 ms
OFF: 8 ms
ON: 3.2 µs
OFF: 0.6 µs
ON: 33 µs…0.1 ms
OFF: 22 µs…0.02 ms
IEC input compatibility Type 3
AC input filter setting 8 ms for all embedded inputs
(In Connected Components Workbench, go to the Embedded I/O configuration window to reconfigure the filter setting for
each input group)
Isolated AC Inputs
Attribute 2080-LC30-16QWB, 2080-LC30-16QVB
(Inputs 0…3)
On-state voltage, nom 12/24V AC @ 50/60 Hz
Off-state voltage, min 4V AC @ 50/60 Hz
Operating frequency, nom 50/60 Hz
Outputs
Attribute 2080-LC30-16AWB,
2080-LC30-16QWB
2080-LC30-16QVB
Relay Output Hi-Speed Output
(Outputs 0…1)
Standard Output
(Outputs 2…5)
Number of outputs 6 2 4
Output voltage, min 5V DC, 5V AC 10.8V DC 10V DC
Output voltage, max 125V DC, 265V AC 26.4V DC 26.4V DC
