Allen-Bradley Micro830 User Manual

Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 181
Using microSD Cards Chapter 10
Controller settings
[PM] Powerup Power up and switch to PROGRAM mode.
[CF] Powerup Power up and attempt to clear fault.
Project settings
[BKD = My Proj1] Powerup Power up and save the controller project into
backup directory,
My Proj1\USERPRJ. Require extra power cycle to
clear existing fault first using [CF] setting or other
means.
[RSD = MyProj2] Powerup Power up and read the project from restore directory
MyProj2\USERPRJ into controller. Require extra
power cycle to clear existing fault first using [CF]
setting or other means. This setting overwrites UPD
(or its default) load always or load on error restore
function.
[UPD = My Proj] Powerup and
Insertion
For normal usage of backup and restore (that is,
through Connected Components Workbench, Load
Always, or Load on Memory Error settings), set the
user project directory name. For example, My Proj,
during powerup or when the microSD card is
inserted.
This directory is also used by data logging and
recipe function.
Network settings
[ESFD] Powerup Embedded Serial Factory Defaults.
Power up and revert embedded serial comms to
factory defaults.
[IPA = xxx.xxx.xxx.xxx] Powerup Power up and set IP address to xxx
(must be numbers only).
[SNM = xxx.xxx.xxx.xxx] Powerup Power up and set subnet mask to xxx
(must be numbers only).
[GWA = xxx.xxx.xxx.xxx] Powerup Power up and set gateway address to xxx
(must be numbers only).
General settings
[END] Powerup End of setting.
This setting is always required even when the
ConfigMeFirst.txt file does not contain any other
setting. The SD LED goes off when this setting is
not present.
IMPORTANT
Flash Upgrade Settings
With Connected Components Workbench software version 12 or later,
you can flash upgrade your Micro800 controller from the microSD card in
addition to using ControlFLASH. See Flash Upgrade From MicroSD Card
on page 250 for instructions.
• [FWFILE] and [FWDOWN] settings must be placed at the beginning of
the file.
ConfigMeFirst.txt Configuration Settings
Setting Takes Effect On... Description
