200 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019
Chapter 10 Using microSD Cards
Build and download
After configuring data log properties, build the program and download to the
controller.
Execute DLG function block
Execute the DLG function block. Notice the Status output go from 0 (Idle) to
1 (Enable), and 2 (Succeed).
Upload data log file
You can retrieve data log files from the microSD card using a card reader or by
uploading the data logs through Connected Components Workbench.
1. To use the Upload feature, go to the Properties section of your project in
Connected Components Workbench.
2. Select Data Log. Click Manage and then choose Upload.
The Manage button is not available in DEBUG mode. You need to stop
DEBUG mode to use the Manage button to upload data log files.
Uploading data log files in PROGRAM mode is recommended for
performance and file locking reasons.
