Allen-Bradley Micro830

Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 265
Quickstarts Appendix C
This quickstart includes the following sections:
• Create the HSC Project and Variables
on page 266
• Assign Values to the HSC Variables on page 269
• Assign Variables to the Function Block on page 272
• Run the High Speed Counter
on page 273
• Use the Programmable Limit Switch (PLS) Function
on page 275
Quadrature Encoder
A
B
Input 0
Input 1
Reverse Rotation
Forward Rotation
B
A
1
2
3
2
1
Count
