Allen-Bradley Micro830 User Manual

Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 49
Wire Your Controller Chapter 4
2080-LC30-24QVB / 2080-LC30-24QBB / 2080-LC50-24QVB /
2080-LC50-24QBB / 2080-LC70-24QBB / 2080-LC70-24QBBK
2080-LC30-24QBB, 2080-LC50-24QBB, 2080-LC70-24QBB, 2080-LC70-24QBBK,
DC Input Configuration
I-00
COM0 I-01
I-02
I-03
I-04
I-05
I-06 COM1
I-07
I-09
I-08
123456789101112
+DC24 +CM0
O-00-DC24
O-01
-CM0
+CM1
O-02 O-04
O-03
O-06
O-05
123456789101112
I-11
I-10
I-13
I-12
13 14 15 16
O-08
O-07
-CM1
O-09
13 14 15 16
45020
Input terminal block
Output terminal block
I-00
COM0 I-01
I-02
I-03
I-04
I-05
I-06 COM1
I-07
I-09
I-08
123456789101112
+DC24 +CM0
O-00-DC24
O-01
-CM0
+CM1
O-02 O-04
O-03
O-06
O-05
123456789101112
I-11
I-10
I-13
I-12
13 14 15 16
O-08
O-07
-CM1
O-09
13 14 15 16
-24 VDC
+24 VDC
N
L
L1 L2
2080-PS120-240VAC
-DC d
CR CR
Sourcing:+DC b
Sinking: -DC b
Sourcing:-DC b
Sinking: +DC b
Sourcing:+DC a
Sinking: -DC a
Sourcing:-DC a
Sinking: +DC a
-DC e
+DC e
+DC d
IMPORTANT
• Do not connect –DC24 (Output terminal 2) to Earth/Chassis Ground.
• In Micro870 systems that use more than four Micro800 Expansion
I/O modules, we recommend to use a 1601-XLP60EQ power supply
instead of a 2080-PS120-240VAC power supply. Make sure to wire
both the Micro870 controller and 2085-EP24VDC expansion power
supply to the same 1601-XLP60EQ power supply.
