54 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019

Chapter 4 Wire Your Controller

Sink input wiring example

Com

Fuse

24V

I/P

45627

Source output wiring example

Micro800 Source output

DC COM

OUT

+V DC

–

24V supply

Logic side

User side

Load

Fuse

45626

Source input wiring example

Com

Fuse

24V

I/P

45625
