Allen-Bradley micrologix 1500 Reference Manual

Publication 1762-RM001C-EN-P
1-2 I/O Configuration
AC embedded inputs have fixed input filters. DC embedded inputs have
configurable input filters for a number of special functions that can be
used in your application. These are: high-speed counting, event
interrupts, and latching inputs. The 1764-28BXB has two high-speed
outputs for use as pulse train output (PTO) and/or pulse width
modulation (PWM) outputs. The 1762-L24BXB and -L40BXB each have
one high-speed output.

Allen-Bradley micrologix 1500 Specifications

General

Processor Type	16-bit
Programming Language	Ladder Logic
Mounting	DIN rail or panel mount
Programming Software	RSLogix 500
Communication Ports	RS-232
Power Supply	24V DC
Operating Temperature	0°C to 55°C (32°F to 131°F)
Controller Type	Programmable Logic Controller (PLC)
