Publication 1762-RM001C-EN-P
Communications Instructions 21-9
Configuring a Local
Message
Message Setup Screen
The rung below shows a MSG instruction preceded by conditional logic.
Access the message setup screen by double-clicking Setup Screen.
The RSLogix Message Setup Screen is shown below. This screen is used to
setup This Controller, Target Device, and Control Bits. Descriptions
of each of the elements follow.
0000
B3:0
0
EN
DN
ER
MSG
Read/Write Message
MSG File MG11:0
Setup Screen
MSG
