Publication 1762-RM001C-EN-P

21-8 Communications Instructions

Example 3 - Local DF1 Half-Duplex Network

Rockwell Software RSLinx 2.0 (or

higher), SLC 5/03, SLC 5/04, and

SLC 5/05, or PLC-5 processors

configured for DF1 Half-Duplex

Master.

RS-232

(DF1 Half-Duplex Protocol)

MicroLogix

1500 (Slave)

SLC 5/04 (Slave)

MicroLogix

1000 (Slave)

SLC 5/03 with 1747-KE

Interface Module (Slave)

MicroLogix

1200 (Slave)

Modem

NOTE

It is recommended that isolation (1761-NET-AIC) be

provided between the controller and the modem.
