Publication 1762-RM001C-EN-P
I/O Configuration 1-5
Analog I/O Configuration
1762-IF2OF2 Input Data File
For each input module, slot x, words 0 and 1 contain the analog values of
the inputs. The module can be configured to use either raw/proportional
data or scaled-for-PID data. The input data file for each configuration is
shown below.
The bits are defined as follows:
Sx = General status bits for channels 0 and 1. This bit is set when an
error (over- or under-range) exists for that channel, or there is a
general module hardware error.
Ox = Over-range flag bits for channels 0 and 1. These bits can be used
in the control program for error detection.
Ux = Under-range flag bits for channels 0 and 1. These bits can be
used in the control program for error detection.
Table 1.1 Raw/Proportional Format
Word
Bit Position
1514131211109876543210
0 0 Channel 0 Data 0 to 32768 0 0 0
1 0 Channel 1 Data 0 to 32768 0 0 0
2reserved
3reserved
4reserved S1S0
5 U0O0U1O1reserved
Table 1.2 Scaled-for-PID Format
Word
Bit Position
1514131211109876543210
0 0 0 Channel 0 Data 0 to 16,383 0 0
1 0 0 Channel 1 Data 0 to 16,383 0 0
2 reserved
3 reserved
4 reserved S1 S0
5 U0O0U1O1reserved
