Publication 1762-RM001C-EN-P
C-16 System Status File
User Fault Routine File Number
This register is used to control which subroutine executes when a User
Fault is generated.
STI Set Point
This address is duplicated at STI:0/SPM. SeeUsing the Selectable Timed
Interrupt (STI) Function File on page 18-12 for more information.
STI File Number
This address is duplicated at STI:0/PFN. SeeUsing the Selectable Timed
Interrupt (STI) Function File on page 18-12 for more information.
Channel 0 Communications
Incoming Command Pending
This address is duplicated in the Communications Status File at CS0:0.4/0.
See General Channel Status Block on page 3-14 for more information.
Message Reply Pending
This address is duplicated in the Communications Status File at CS0:0.4/1.
See General Channel Status Block on page 3-14 for more information.
Address Data Format Range Type User Program Access
S:29 word 0 to 255 status read only
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:30 word 0 to 65535 status read only
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:31 word 0 to 65535 status read only
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:33/0 binary 0 or 1 status read only
Address
(1)
(1) This bit can only be accessed via ladder logic. It cannot be accessed via communications (such as a Message
instruction from another device).
Data Format Range Type User Program Access
S:33/1 binary 0 or 1 status read only
