Rockwell Automation Publication 2711R-UM001E-EN-E - January 2017 29
Configuration Mode Chapter 2
Follow these steps to configure the screen saver from the terminal.
1. Go to the main configuration screen.
2. Press Display.
3. Select the Mode.
Mode = Disable, Image, Dimmer, Image and Dimmer.
4. Select the brightness.
Brightness 0…100, increments of 1.
5. Select the idle timeout.
Choices are 1, 2, 5, 10, 15, 20, 30, or 60 min.
Main
File Manager
Communication
Display
System Information
Current Application
Config Language Date and Time
Day Hour
Reset Terminal
Goto
14 10
Month Minute
1 30
Year Second
2015 56
English
Português
Français
Italiano
Deutsch
Español
简体中文
Display
Screen Saver
Back
Brightness
Mode
Brightness
Timeout
Orientation (Requires Reset)
Calibrate Touchscreen
100
0 degrees
11
10 Min
To Next Page
